网•网络应用平台
NCA-6110
应用交付、网络安全和广域网优化的高性能解决方案
- AMD EPYC 7000系列，支持 Naples(32C64T)和Rome(64C128T)
- 16x 288-pin DIMM, Max. 512GB DDR4 2666MHz ECC R-DIMM
- 2个GbE RJ45 Intel®i210，最大支持8个网卡模块槽位
- 最大4x个3.5”或2.5”可交换插槽，1个RJ45 Console
- 2x PCIe*8 FHHL或1x PCIe*16 FHFL
NCA-6110是专为网络安全、应用交付和广域网优化而设计的，它支持AMD的第二代EPYC cpu，代号为Rome。这次处理器更新保留了NCA-6110的所有其他突出特性。
产品规格
| Platform | |
| Form Factor | 2U 19” Rackmount |
| Processor Options | AMD EPYC 7000 Series w/ Support for Naples (up to 32C64T) & Rome (up to 64C128T) |
| CPU Socket | SP3 |
| Chipset | N/A |
| Security Acceleration | 40Gbps Encryption + 40Gbps Decryption |
| BIOS | AMI SPI Flash BIOS |
| System Memory | |
| Technology | DDR4 2666MHz ECC REG DIMM |
| Max. Capacity | 512GB |
| Socket | 16x 288-pin DIMM |
| Networking | |
| Ethernet Ports | 2 x GbE RJ45 Intel® i210 |
| Bypass | N/A |
| NIC Module Slot | 8 or 4 (by SKU) |
| LOM | |
| IO Interface | 1 x RJ45 |
| OPMA Slot | Yes |
| I/O Interface | |
| Reset Button | 1 |
| LED | Power/Status/Storage |
| Power Button | 1 x ATX Power Switch |
| Console | 1 x RJ45 |
| USB | 2 x USB 3.0 |
| LCD Module | N/A |
| Display | 1x VGA (Optional) |
| Power Input | AC Power Inlet on PSU |
| Storage | |
| HDD/SSD Support | 4 x 3.5” / 2.5” or 2 x 3.5”/2.5” Swappable Bays |
| Onboard Slots | 1 x mSATA (M.2 by Project) |
| Expansion | |
| PCIe | 2 x PCIe*8 FHHL or 1 x PCIe*16 FHFL |
| Miscellaneous | |
| Watchdog | Yes |
| Internal RTC with Li Battery | Yes |
| TPM | Yes (Optional) |
| Cooling | |
| Processor | Passive CPU Heatsink |
| System | 4 x Individual Hot-swappable Cooling Fans |
| Environmental Parameters | |
| Temperature | 0~40ºC Operating -20~70ºC Non-Operating |
| Humidity (RH) | 5~90% Operating 5~95% Non-Operating |
| System Dimensions | |
| (WxDxH) | 438 x 600 x 88 mm |
| Weight | 24 kg |
| Package Dimensions | |
| (WxDxH) | 825 x 600 x 270 mm |
| Weight | 26 kg |
| Power | |
| Type / Watts | 850W 1+1 ATX Redundant PSUs |
| Input | AC 100V~240V @47~63Hz |
| Certification | |
| Approvals and Compliance | RoHS, CE/FCC, UL |
订购信息
| NCA-6110A |
AMD EYPC 7000系列，w/支持Naples(最多32C64T)和Rome(最多64C128T)， 2x GbE RJ45, 4x NIC模块槽位，1x RJ45 Console |
| NCA-6110B |
AMD EYPC 7000系列，w/支持Naples(最多32C64T)和Rome(最多64C128T)， 2x GbE RJ45, 8x NIC模块槽位，1x RJ45 Console |
All product specifications are subject to change without prior notice
